How much does a retaining wall cost?

Concrete block walls cost $15-$30/sq ft of wall face, natural stone $25-$60/sq ft, and timber $10-$20/sq ft installed. A typical 3-foot-tall, 50-foot-long wall costs $2,250-$9,000 depending on material. Walls over 4 feet require engineering ($500-$2,000 additional). Do I need a permit for a retaining wall?

Do I need a permit for a retaining wall?

Most jurisdictions require permits for retaining walls over 4 feet tall (measured from bottom of footing to top of wall). Some require permits at 3 feet. Walls requiring engineering or near property lines almost always need permits. Check with your local building department. How long does a retaining wall last?

How long does a retaining wall last?

Concrete block walls last 50-100+ years. Natural stone lasts indefinitely with proper construction. Poured concrete lasts 50-100 years. Timber walls last only 10-20 years before rotting. Proper drainage is the key factor in wall longevity. Can I build a retaining wall myself?

Can I build a retaining wall myself?

Walls under 3 feet using concrete blocks or timber are good DIY projects. You'll need gravel for backfill, a perforated drain pipe, and filter fabric. Walls over 3-4 feet should be engineered and professionally built — failure of a tall wall can cause serious property damage.

Article

Framing & Structure

Retaining Wall Guide: Types, Materials, Cost & Installation

Lumberama Editorial Team, Landscaping & Hardscape Specialists Nov 9, 2026 9 min read

Retaining Wall Types

Gravity walls: Rely on weight and mass to hold back soil. Typically stone, concrete, or large blocks. No reinforcement needed for walls under 3-4 feet. Most common residential type.

Cantilever walls: L-shaped reinforced concrete. Leverage soil weight on base slab for stability. Engineered for walls over 4 feet. Cost: more expensive but stronger.

Segmental retaining walls (SRW): Interlocking concrete blocks. Pin or lip connection system. Can be reinforced with geogrid for taller walls. Most popular for residential landscaping.

Anchored walls: Use cables or rods anchored deep into soil behind wall. For very tall walls or challenging soil conditions. Engineering required.

Materials

Concrete block (Allan Block, Versa-Lok): Most popular residential choice. Interlocking with no mortar needed. Cost: $15-$30/sq ft of wall face installed. Many colors and textures. DIY-friendly for walls under 3 feet.

Natural stone: Fieldstone, limestone, granite, or sandstone. Cost: $25-$60/sq ft installed. Most natural appearance. Irregular shapes require skilled mason. Premium look.

Timber/landscape ties: Pressure-treated lumber (6x6 or 8x8). Cost: $10-$20/sq ft installed. Easy DIY. Lifespan: 10-20 years (wood rots eventually). Not recommended over 3 feet. Being replaced by block.

Poured concrete: Strongest option for tall walls. Cost: $20-$40/sq ft installed. Can be faced with stone veneer for appearance. Requires forms and reinforcement. Engineering needed for walls over 4 feet.

Boulder walls: Large natural boulders stacked or placed. Cost: $20-$40/sq ft. Natural, organic appearance. Requires heavy equipment. Not for precise geometry.

Cost

Per square foot of wall face: Timber: $10-$20. Concrete block: $15-$30. Natural stone: $25-$60. Poured concrete: $20-$40. Boulder: $20-$40.

By wall length (3 ft tall x 50 ft long = 150 sq ft face): Timber: $1,500-$3,000. Concrete block: $2,250-$4,500. Natural stone: $3,750-$9,000.

Additional costs: Engineering (walls over 4 ft): $500-$2,000. Permits: $100-$500. Drainage (gravel + pipe): $3-$5/linear foot. Geogrid reinforcement: $1-$3/sq ft.

Drainage

Why it matters: Water pressure behind a wall is the #1 cause of failure. Hydrostatic pressure can be 2-3x the soil pressure alone. Proper drainage is not optional.

Gravel backfill: 12 inches of clean gravel behind wall. Extends full height. Allows water to flow down to drain pipe.

Drain pipe: 4-inch perforated pipe at base of wall behind gravel. Covered with filter fabric. Daylight outlet at low end of wall or connected to storm drain.

Filter fabric: Separates gravel from native soil. Prevents soil from clogging gravel and drain pipe. Wrap around gravel backfill.
